GEAR SPECIFICATION
|
|
DRIVEN MOTOR
|
90Kw * 1750 RPM
|
|
OUTPUT SHAFT SPEED
|
105 RPM
|
|
REDUCTION RATIO
|
1 / 10.406
|
|
LUBRICANT
|
ISO VG 220. 50 LITER
|
|
WEIGHT
|
1000 Kg
|
|
NAME
|
STEP
|
1st GEAR
|
2nd GEAR
|
|
PART
|
PINION
|
GEAR
|
PINION
|
GEAR
|
|
MODULE
|
3.5
|
5.5
|
|
NO DF TEETH
|
22
|
75
|
19
|
58
|
|
PRESSURE ANGLE
|
15 ¢ª
|
10 ¢ª
|
|
HELIX ANGLE
|
(R) 15 ¢ª (L)
|
(R) 10 ¢ª (L)
|
|
RATIO
|
1 / 3.4
|
1 / 3.05
|
|
STANDARD P.C.D
|
79.716
|
271.760
|
106.112
|
323.921
|
|
WIDTH OF TEETH
|
85
|
80
|
115
|
110
|
|
HARDNESS OF TEETH
|
HRc60¡¾2
|
HRc58¡¾2
|
HRc60¡¾2
|
HRc58¡¾2
|
|
MATERIAL
|
SNCM21
|
|
HEAT TREATMENT
|
CARBURIZING
|
|
GRADE
|
JIS 2
|
|
|
| |
|
|
 |
|
